FLUORESCENCE MICROSCOPE
Description:
Specifications
Standard features
- Binocular or Trinocular tube, 45°/ 30 inclined, 360° rotatable, IPD 55-75 mm, with Dioptric adjustment on left
ocular
- Coaxial Fine and Coarse Focusing Knobs on Both Sides of Microscope.Coarse Adjustment Travel
Range: 22mm. (Stage Movement Distance Up/Down).
- Fine Adjustment Division: 0.002mm.,Adjustable Lock Ring Stop to Limit Coarse Range to Protect
Slides,Tension Adjustable Coarse Focusing.
- Wide Field eyepiece WF 10x/16mm paired with eye guards
- DIN Fluorescent Achromatic Objectives 4x,10x,40x (Spring loaded) and 100x (Spring loaded), Oil immersion
- Transmitted Koehler Illumination system 6V-20W Halogen with intensity contro
- Epi-fluorescence unit: power unit 220V, mercury lamp house 100W/DC, epi-fluorescence
illuminator
- Excitation filter (EX) comprising of – Blue light (EX-490), Green Light (EX-545)
- Illumination Box with Power Supply Unit 220 Volt & HBO, Super High – pressured Spherical mercury
vapor lamp 100W
- Instruction Manual, Dust cloth, Dust cover.
Standard Configurations
- DIN Fluorescent Achromatic Objectives 4x,10x,40x (Spring loaded) and 100x (Spring loaded), Oil immersion
- Epi-fluorescence unit: power unit 220V, mercury lamp house 100W/DC, epi-fluorescence
Optional accessories
- DCM 35 Digital Camera for Microscope
